| BTU Cooling Rating | : | 12,000 Btu/hr |
| BTU Heating Rating | : | 13,000 Btu/hr |
| CFM Airflow | : | 350 cfm~610 cfm |
| Depth | : | 8.25 in |
| EER | : | 12.5 |
| HSPF | : | 11.0 |
| Height | : | 12.25 in |
| Liquid Line Size | : | 1/4 in |
| Model Number | : | AW |
| Number of Speeds | : | 5 |
| Packaged Depth | : | 12.38 in |
| Packaged Height | : | 15.75 in |
| Packaged Width | : | 39.00 in |
| Phase | : | 1 ph |
| Product Family | : | Advanced Plus |
| Product Type | : | Wall-Unit |
| Product Weight | : | 25.4 lb |
| Refrigerant Type | : | R-410A |
| SEER | : | 23.0 |
| Shipping Weight | : | 30.9 lb |
| Sound Level | : | 45 dBA |
| Suction Line Size | : | 3/8 in |
| Tonnage | : | 1.0 Ton |
| Voltage Rating | : | 208/230 V |
| Width | : | 35.38 in |
