IPEX® Home-Flex™ 221026 Underground Gas Pipe, 1/2 in Nominal Pipe, Resin, 500 ft L, 1/2 in, CTS, Yellow, 5/8 in OD
IPEX® Home-Flex™ 221026 Underground Gas Pipe, 1/2 in Nominal Pipe, Resin, 500 ft L, 1/2 in, CTS, Yellow, 5/8 in OD
Manufacturer: Aliaxis Group SA
Brand: IPEX®
Part #: 297808
MPN: 221026
CPN:
| ASTM Specifications | : | Yes |
| Color | : | Yellow |
| Connection Size 1 | : | 1/2 in |
| Connection Type 1 | : | CTS |
| Length | : | 500 ft |
| Material | : | Resin |
| Maximum Working Pressure | : | 125 psi |
| NSF Specifications | : | Yes |
| Nominal Pipe Size | : | 1/2 in |
| Operating Temperature Rating | : | 140 deg F |
| Outside Diameter | : | 5/8 in |
| Product Family | : | Home-Flex™ |
| Product Type | : | Pipe |
| Standard Dimension Ratio (SDR) | : | SDR 7 |
| Wall Thickness | : | 0.09 in |
PE Gas Pipe and Tubing is a lightweight and flexible product for natural gas and LPG distribution systems. Designed for use with heat and electrofusion fittings, PE gas piping provides a long life of leak-free connections. Polyethylene is flexible and easy to join, requiring minimal labor to install. Benefits include strong chemical resistance and lack of susceptibility to rust, rot, or electrolysis.
IPEX® Underground Gas Pipe, Pipe, 1/2 in Nominal Pipe, Resin, 500 ft L, 1/2 in, CTS, Yellow, 5/8 in OD, 0.09 in Thick Wall, SDR 7, Yes, Yes, 125 psi Max Working Pressure, 140 deg F, Home-Flex™
- Used in natural gas and LPG distribution systems
- Intended for outside underground installation
- Designed to be joined with mechanical, heat, and electrofusion fittings
- Gas pipe is offered in IPS, 3/4" through 4" in SDR-11, 1-1/4" in DR-10 and 1/2" in DR-9.3, as well as CTS,1" in SDR-11.5 and 1/2" in SDR-7
