| Color | : | Ivory |
| Connection Type | : | Flared |
| Cooling BTU Rating | : | 5800 to 18000 Btu/hr |
| Cooling CFM Rating | : | 1166 cfm |
| Cooling Operating Temperature | : | 95 deg F |
| Cooling Sound Level | : | 53 dBA |
| Drive Type | : | Inverter |
| EER Rating | : | 9.5 |
| Frequency Rating | : | 60 Hz |
| Fuse Rating | : | 20 A |
| HSPF Rating | : | 8.5 |
| Heating BTU Rating | : | 5400 to 20800 Btu/hr |
| Heating CFM Rating | : | 1152 cfm |
| Heating Operating Temperature | : | 47 deg F |
| Heating Sound Level | : | 51 dBA |
| Liquid Line Size | : | 1/4 in |
| Overall Height | : | 21-5/8 in |
| Overall Length | : | 31-1/2 in |
| Overall Width | : | 11-1/4 in |
| Phase | : | 1 ph |
| Power Rating | : | 1680 W |
| Refrigerant Type | : | R-454B |
| SEER Rating | : | 9.5 |
| Series | : | MSZ-WX-NL Series |
| Suction Line Size | : | 1/2 in |
| Voltage Rating | : | 208/230 V |
