Navien NPE-240A2-NG NPE-A2 Series 11.2 GPM Gas Tankless Water Heater - 199,900 BTU/h, 120V, Low NOx, 0.95 Energy Factor
Navien NPE-240A2-NG NPE-A2 Series 11.2 GPM Gas Tankless Water Heater - 199,900 BTU/h, 120V, Low NOx, 0.95 Energy Factor

Navien NPE-240A2-NG NPE-A2 Series 11.2 GPM Gas Tankless Water Heater - 199,900 BTU/h, 120V, Low NOx, 0.95 Energy Factor

Navien NPE-240A2-NG NPE-A2 Series 11.2 GPM Gas Tankless Water Heater - 199,900 BTU/h, 120V, Low NOx, 0.95 Energy Factor

Manufacturer: NAVIEN INC
Brand: Navien
Part #: 301478
MPN: NPE-240A2-NG
CPN:
Amperage Rating      :      2~4 A
BTU Heating Input Rating (Custom)      :      204,000 BTU/h
BTU Heating Input Rating      :      199,900 BTU/h
Condensing      :      Yes
Depth      :      13.2 in
ENERGY STAR Certified      :      Yes
Energy Factor      :      0.95
Flow Rate      :      11.2 GPM
Fuel Type      :      Natural Gas
Gas Connection Size      :      3/4 in
Height      :      27.4 in
Installation / Mounting Type      :      Wall Mount
Low NOx      :      Low NOx
Maximum Working Pressure      :      150 PSI
Minimum Working Pressure      :      15 PSI
Model Number      :      NPE-A2
Packaged Depth      :      34.5 in
Packaged Height      :      16.5 in
Packaged Width      :      16.5 in
Phase      :      1 ph
Product Family      :      NPE-A2 Series
Product Weight      :      77 lbs
Shipping Weight      :      100 lbs
Vent Size      :      2~3 in
Vent Type      :      Direct Vent
Voltage Rating      :      120 V
Water Connection Size      :      3/4 in
Width      :      17.3 in

The Navien NPE-A2 Series is a high-efficiency condensing tankless water heater designed for reliable on-demand hot water in residential and light commercial applications. It delivers a flow rate of 11.2 GPM powered by a 199,900 BTU/h input and features Navien's ComfortFlow™ technology with an integrated recirculation pump, providing faster hot water delivery while minimizing water waste.Built for longevity and performance, the unit is equipped with dual stainless steel heat exchangers. It offers significant installation flexibility with options for indoor or outdoor mounting and long vent runs using standard PVC pipe, making it an adaptable solution for both new construction and retrofit projects.

ComfortFlow™ Technology: Features an integrated recirculation pump and a 0.5-gallon buffer tank to reduce wait times for hot water and eliminate temperature fluctuations.Durable Construction: Equipped with dual primary and secondary stainless steel heat exchangers for enhanced durability and resistance to corrosion.Installation Flexibility: Compatible with 1/2-inch gas lines up to 24 feet and allows for long vent runs with 2-inch PVC up to 75 feet, simplifying installation in various settings.System Scalability: Ready-Link cascading technology allows for linking up to 32 units to meet high-demand hot water needs in larger residential or commercial applications.User-Friendly Controls: Includes an EZNav multi-line control panel for straightforward setup and diagnostics, and is compatible with the optional Nav-Link Wi-Fi control module.Fuel Versatility: Can be field-converted from natural gas to propane operation using the included kit, providing flexibility for different job site requirements.
