PROTECH™ 5440H Condenser Motor, 1/8 to 1/12 hp Motor, 208/230 V, 1 ph, 1075 rpm Motor, 42 NEMA, 1 -Speed, 3 in L Shaft
PROTECH™ 5440H Condenser Motor, 1/8 to 1/12 hp Motor, 208/230 V, 1 ph, 1075 rpm Motor, 42 NEMA, 1 -Speed, 3 in L Shaft
| Bearing Type | : | Ball |
| Depth | : | 5 in |
| Frequency Rating | : | 60 Hz |
| Function Type | : | Motor |
| Motor HP | : | 1/8 to 1/12 hp |
| Motor RPM | : | 1075 rpm |
| Mounting Type | : | Shell Band/Shell Screw/Thru-Bolt |
| NEMA Frame Size | : | 42 |
| Number of Speeds | : | 1 |
| Packaged Depth | : | 12.9 in |
| Packaged Height | : | 6.9 in |
| Packaged Width | : | 7.2 in |
| Phase | : | 1 ph |
| Shaft Diameter | : | 1/2 in |
| Shaft Length | : | 3 in |
| Shipping Weight | : | 9.2 lb |
| Voltage Rating | : | 208/230 V |
| Width | : | 5 in |
The Mojave® series of condenser fan motor replacement parts is designed for residential and commercial condenser fan motors in extreme temperature locations. This AC condenser fan motor combines the features of both the Emerson™ RESCUE® and Mojave 70C air conditioner motors; this AC motor drives the condenser fan that blows air over the AC condenser coil, enhancing heat dissipation for HVAC/R systems.
PROTECH™ Condenser Motor, 1/8 to 1/12 hp Motor, 208/230 V, 1 ph, 1075 rpm Motor, 42 NEMA, 1 -Speed, 1/2 in Dia Shaft, 3 in L Shaft, 5 in W, 5 in D, 9.2 lb, 6.9 in, 7.2 in, 12.9 in, Motor, Ball Bearing, 60 Hz, Shell Band/Shell Screw/Thru-Bolt Mounting
- Designed for 158 deg F (70 deg C) ambient
- Class F insulation
- Special corrosion protection for longer life in humid environments
- 48 inch leads
- Continuous duty condenser motor
- Automatic reset thermal overload protector
- Extended studs
- Drain holes both ends
