| Amperage Rating | : | 40 A |
| Coil Voltage | : | 24 V |
| Function Type | : | Contactor |
| Number of Poles | : | 3 |
| Packaged Depth | : | 3.82 in |
| Packaged Height | : | 2.73 in |
| Packaged Width | : | 3.16 in |
| Product Family | : | TrueLine™ |
| Shipping Weight | : | 0.85 lb |
The Contactor controls the flow of electricity to your air conditioner's components. The Contactor receives a low voltage signal from the furnace to power on.
Rheem® Contactor, 3 Poles, Product Family: TrueLine™, Contactor Function Type, 40 A, 24 V Coil Voltage
- HVAC Control Relay
- Sealed Case
- Contact Configuration: SPDT
- Contact Bias: NO / NC
- Coil Voltage (VAC): 24
- Coil Frequency (Hz): 50/60
- FLA at 120V (A): 14
- FLA at 230V (A): 8
- LRA at 120V (A): 84
- LRA at 230V (A): 48
- Resistive Rating at 277V (A): 25
- Terminal Connections: 1/4 in. Quick Connects
