| Actuator Type | : | Non-Spring Return |
| Amperage Rating | : | 1.5 A |
| Damper Type | : | Rotary |
| Depth | : | 8 in |
| Diameter | : | 8 in |
| Duct Shape | : | Round |
| For Duct Size | : | 8 in |
| For Use With | : | Zoning System |
| Function Type | : | Motorized Damper |
| Length | : | 12 in |
| Material Gauge | : | 24 ga |
| Material | : | Galvanized Steel |
| Maximum Static Pressure | : | 1.5 in w.c. |
| Motorized | : | Yes |
| Package Quantity | : | 1 |
| Packaged Depth | : | 12 in |
| Packaged Height | : | 12 in |
| Packaged Width | : | 12 in |
| Product Family | : | URD Series |
| Shipping Weight | : | 5.3 lbs |
| Voltage Rating | : | 24 V |
| Width | : | 8 in |
