| Air Flow Direction | : | Vertical |
| BTU Cooling Rating | : | 42,000 BTU/h |
| Compressor Type | : | Scroll |
| Depth | : | 33.75 in |
| EER2 Range | : | 8.5-12.5 |
| EER2 | : | 8.0~9.0~10.0~11.0~12.0 |
| Energy Star Certified | : | Yes |
| Height | : | 27 in |
| Liquid Line Size | : | 3/8 in |
| Max Breaker Size | : | 35 A |
| Minimum Circuit Ampacity (MCA) | : | 23 A |
| Model Number | : | RA13NY |
| Number of Stages | : | Single-Stage |
| Packaged Depth | : | 36.38 in |
| Packaged Height | : | 28.5 in |
| Packaged Width | : | 36.38 in |
| Phase | : | 1 ph |
| Product Family | : | Endeavor Line Classic |
| Product Weight | : | 217 lbs |
| Refrigerant Type | : | R-454B |
| SEER2 Range | : | 13.4-15.5 |
| SEER2 | : | 13.0~14.0~15.0 |
| Shipping Weight | : | 224 lbs |
| Sound Level | : | 68 dB(A) |
| Suction Line Size | : | 7/8 in |
| Tonnage | : | 3.5 Ton |
| Voltage Rating | : | 208/230 V |
| Width | : | 33.75 in |
The Rheem® Endeavor Line Classic Series RA13NY is a single-stage air conditioner designed to provide reliable and efficient cooling. With a SEER2 rating of up to 15.5, this 3.5-ton unit is ENERGY STAR certified and offers dependable performance for residential applications.This unit operates on the lower-GWP R-454B refrigerant, meeting modern environmental standards. It is engineered with features focused on durability and ease of service, making it a practical choice for both new installations and system replacements.
- Enhanced Serviceability: Features PlusOne® Expanded Valve Space and Triple Service Access, providing a minimum of 27 square inches of working area and a 15-inch wide corner access panel for easier and faster repairs.
- Refrigerant Safety: Includes the integrated PlusOne® Refrigerant Detection System™, a patented design that monitors for low-GWP refrigerant and automatically pauses operation if a leak is detected.
- Efficient Coil Design: Equipped with a 7mm copper condenser coil that requires less refrigerant, allowing for a smaller and lighter unit footprint while enhancing reliability.
- Durable Construction: Built with a composite basepan, powder-coated paint, and rust-resistant screws to ensure long-lasting performance and protection against the elements.
- Reliable Operation: A scroll compressor delivers dependable, single-stage cooling performance for consistent home comfort.
