| Air Flow Direction | : | Upflow~Downflow~Horizontal~Multi-Position |
| BTU Rating | : | 24,000 BTU/h |
| Coil Casing | : | Cased |
| Coil Material | : | Aluminum Fin~Aluminum Tube |
| Depth | : | 21.6 in |
| Drain Pan Material | : | Composite / Polymer |
| Height | : | 23 in |
| Liquid Line Size | : | 3/8 in |
| Model Number | : | RCFY |
| Number of Rows | : | 2 |
| Product Family | : | Endeavor |
| Product Weight | : | 45 lbs |
| Refrigerant Type | : | R-454B |
| Refrigeration Control Type | : | TXV |
| Shipping Weight | : | 49 lbs |
| Suction Line Size | : | 3/4 in |
| Tonnage | : | 2.0 Ton |
| Width | : | 14 in |
The Rheem® Endeavor Series cased A-coil is engineered for use with gas and oil furnaces in multi-position applications, including upflow, downflow, and horizontal configurations. It provides 2.0 tons of nominal cooling capacity and is designed to be paired with Rheem® outdoor units for a complete, AHRI-certified system.This coil is constructed with all-aluminum tubing and fins to ensure long-lasting performance and is factory leak-tested for reliability. Featuring a TXV metering device, it is optimized for the new low-GWP R-454B refrigerant, providing an efficient and compliant solution for residential cooling systems.
- Refrigerant Detection System: Includes the PlusOne® Refrigerant Detection System™, an integrated A2L sensor and mitigation board that automatically pauses system operation if excess refrigerant is detected.
- Flexible Installation: Features bi-directional airflow, eliminating the need to reconfigure internal components for horizontal left or right applications.
- Durable Construction: Built with aluminum fins bonded to internally grooved aluminum tubing for reliable performance and efficient heat transfer.
- Advanced Condensate Management: Equipped with a high-grade, corrosion-free thermal-set drain pan that is UV resistant and has two 3/4 in N.P.T. drain connections for flexible connection.
- Low GWP Refrigerant: Designed specifically for use with R-454B refrigerant to meet modern environmental and efficiency standards.
