| BTU Cooling Rating | : | 60,000 BTU/h |
| BTU Heating Rating | : | 55,000 BTU/h |
| Coefficient of Performance (COP) | : | 3.5 |
| Compressor Type | : | Scroll |
| Depth | : | 35.75 in |
| EER2 (Custom) | : | 8.0-12.0 |
| EER2 | : | 8.0~9.0~10.0~11.0~12.0 |
| Energy Star Certified | : | Yes |
| HSPF2 (Custom) | : | 6.8-7.8 |
| HSPF2 | : | 6.0~7.0 |
| Height | : | 39 in |
| Liquid Line Size | : | 3/8 in |
| Max Breaker Size | : | 50 A |
| Minimum Circuit Ampacity (MCA) | : | 33 A |
| Model Number | : | RP14AY |
| Number of Stages | : | Two-Stage |
| Packaged Depth | : | 38.38 in |
| Packaged Height | : | 40.5 in |
| Packaged Width | : | 38.38 in |
| Phase | : | 1 ph |
| Product Family | : | Endeavor Line Classic |
| Product Weight | : | 275 lbs |
| Refrigerant Type | : | R-454B |
| SEER2 (Custom) | : | 12.0-15.5 |
| SEER2 | : | 12.0~13.0~14.0~15.0 |
| Shipping Weight | : | 282 lbs |
| Sound Level | : | 74 dB(A) |
| Suction Line Size | : | 7/8 in |
| Tonnage | : | 5.0 Ton |
| Voltage Rating | : | 208/230 V |
| Width | : | 35.75 in |
The Rheem Endeavor Line Classic RP14AY is a two-stage heat pump condenser designed for reliable, year-round home comfort. It delivers efficient performance with a SEER2 rating up to 15.5, while its two-stage scroll compressor helps maintain consistent temperatures and control humidity.This ENERGY STAR® certified unit utilizes low-GWP R-454B refrigerant, reducing its environmental impact without sacrificing performance. Engineered for quiet operation and durability, it features a robust cabinet and sound-dampening technologies to ensure it runs smoothly and unobtrusively.
Two-Stage Operation: Features a two-stage scroll compressor that provides precise temperature control, improved humidity management, and greater efficiency compared to single-stage units.Enhanced Serviceability: PlusOne® Triple Service Access and Expanded Valve Space provide ample room for easier and faster repairs, with a 15-inch wide corner access and a 27-square-inch working area.Refrigerant Safety: The integrated PlusOne® Refrigerant Detection System™ includes an A2L sensor and mitigation board to protect the system and provide peace of mind with low-GWP refrigerants.Durable Construction: Built with a corrosion-resistant composite base pan, rugged corner posts, and a powder coat paint system to protect internal components and maintain cabinet aesthetics.Reliable Performance: An inverted reversing valve allows for faster heat transfer and reduced joint stress, increasing the unit's long-term reliability.Conditional Warranty: Covered by a 10-year conditional parts warranty upon registration.
