| BTU Cooling Rating (Custom) | : | 40,800 BTU/h |
| BTU Cooling Rating | : | 42,000 BTU/h |
| Compressor Oil Type | : | POE Oil |
| Compressor Type | : | Scroll |
| Depth | : | 9.69 in |
| Discharge Line Size | : | 1/2 in |
| Function Type | : | Compressor |
| Height | : | 19.94 in |
| Locked Rotor Amps (LRA) | : | 129 A |
| Package Quantity | : | 1 |
| Phase | : | 1 ph |
| Product Family | : | ZR Series |
| Product Weight | : | 68.3 lbs |
| Rated Load Amps (RLA) | : | 22.1 A |
| Refrigerant Type | : | R-407C~R-22 |
| Suction Line Size | : | 7/8 in |
| Tonnage | : | 3.5 Ton |
| UL Listed | : | Yes |
| Voltage Rating | : | 208/230 V |
| Width | : | 9.69 in |
The ZR Series scroll compressor is engineered for reliable performance in high-temperature and air conditioning applications. It delivers a nominal cooling capacity of 3.5 tons, providing efficient and consistent operation.Designed for versatility, this single-phase compressor operates on 208/230V power and is compatible with both R-22 and R-407C refrigerants. Its robust scroll technology makes it an excellent choice for new installations or as a service replacement.
