Yellow Jacket® 49118 Manifold Gauge, R-32, R-410A, R-454B Refrigerant, 0 to 800 psi Gauge Pressure Range, Analog Display
Yellow Jacket® 49118 Manifold Gauge, R-32, R-410A, R-454B Refrigerant, 0 to 800 psi Gauge Pressure Range, Analog Display
Manufacturer: Ritchie Engineering Company, Inc
Brand: Yellow Jacket®
Part #: 296997
MPN: 49118
CPN:
| Accuracy | : | 1 % |
| Body Material | : | Brass |
| Color | : | Blue |
| Connection Size | : | 1/8 in |
| Connection Type | : | Male NPT |
| Display Type | : | Analog |
| Gauge Diameter | : | 3-1/8 in |
| Gauge Pressure Range | : | 0 to 800 psi |
| Maximum Working Pressure | : | 800 psi |
| Product Type | : | Gauge |
| Refrigerant Type | : | R-32, R-410A, R-454B |
With 1% accuracy (Class 1) calibration. Large 3-1/8" gauges are housed in a red or blue steel case with front recalibrator screw. High visibility colored temperature scales are easy to read through the full view polycarbonate crystal.
Yellow Jacket® Manifold Gauge, R-32, R-410A, R-454B Refrigerant, 0 to 800 psi Gauge Pressure Range, 1/8 in Connection, Analog Display, 800 psi Maximum Working Pressure, 1 % Accuracy, Brass Body, Gauge Diameter: 3-1/8 in, Male NPT Connection, Blue
- Flutterless™ technology with brass surge protector to minimize needle pulsation
- Brass gauge movement
- Copper alloy Bourdon tube
- 1/8" NPT Male connection
- Calibrated to 1% accuracy
- Color-coded red for pressure and blue for compound
- Color-coded refrigerant types
