| Amperage Rating | : | 3.5~4.1 A |
| Bearing Type | : | Sleeve |
| Depth | : | 5.5 in |
| Enclosure Type | : | OAO |
| For Use With | : | Furnace |
| Function Type | : | Blower Motor |
| Height | : | 14.8 in |
| Motor HP | : | 1/5~3/4 HP |
| Motor RPM | : | 1,075 RPM |
| Motor Type | : | PSC |
| NEMA Frame Size | : | 48 |
| Number of Shafts | : | 1 |
| Number of Speeds | : | 4 |
| Package Quantity | : | 1 |
| Phase | : | 1 ph |
| Product Weight | : | 17.2 lbs |
| Rotation Direction | : | Reversible |
| Service Factor | : | 1.00 |
| Shaft Diameter | : | 0.5 in |
| Shaft Length | : | 5.23 in |
| Voltage Rating | : | 208/230 V |
| Width | : | 5.5 in |
This MARS direct-drive blower motor serves as a versatile, multi-horsepower replacement for a wide range of furnace applications. Designed to be an ideal truck-stock component, a single motor covers four-speed applications from 1/5 HP up to 3/4 HP, simplifying inventory management for service professionals. This 208/230V PSC motor operates at 1,075 RPM and is thermally protected for reliable, continuous air-over duty.
Multi-Horsepower Design: Covers a range of applications from 1/5 to 3/4 HP, making it an ideal motor for service vehicle stock.Flexible Installation: Features reversible rotation and includes pre-installed screws in Rheem mounting holes for versatile use.Versatile Mounting: Supports belly band, thru-bolt, and resilient ring mounting options to fit various system configurations.Durable Operation: Built with Class B insulation and automatic thermal overload protection for a long service life.Adjustable Performance: Provides four operating speeds, allowing airflow to be tailored to specific system requirements.Reliable Bearings: Equipped with all-angle sleeve bearings for quiet, continuous-duty performance.
